Problem
In some applications, 2D systems cannot evaluate depth and height differences with sufficient accuracy. This creates quality risk especially for products that require volumetric shape and geometry control.
SOLUTION DETAIL
3D Imaging
Use 3D imaging for quality control tasks that require depth, height and volume information.
Visiomex 3D imaging solutions evaluate not only the surface, but also the geometric structure of the product numerically.
System Structure
Camera, lighting, decision logic and automation integration form the core layers of the solution architecture.
Solution
Visiomex uses 3D sensors and analysis software to generate a height map, compare critical geometries and automatically identify out-of-tolerance deviations.
Outcome
3D imaging increases measurement accuracy, detects geometric deviations earlier and strengthens process control.
Benefits
- More accurate geometric control
- Reliable analysis of height differences
- Lower false-accept risk
- Measurement-driven quality decisions
Related Technologies
3D sensorsHeight map analysisGeometric comparisonTolerance control softwareData logging
Use Cases
- Geometric form inspection
- Fill-level / volume analysis
- Height-difference inspection
- Precision mounting surface measurement
